--- title: Microsoft Azure Blob Storage summary: null url: >- https://www.fastly.com/documentation/guides/integrations/non-fastly-services/microsoft-azure-blob-storage --- [Microsoft Azure Blob Storage](https://azure.microsoft.com/en-us/services/storage/blobs/) public and private containers can be used as [origins](https://www.fastly.com/documentation/guides/getting-started/hosts/working-with-hosts) with Fastly. > **HINT:** With properly configured services in place, shared Fastly and Microsoft customers will benefit from Fastly’s integration with Azure’s ExpressRoute Direct Local, which results in Fastly including your outbound data transfer costs from Azure in your standard Fastly pricing. See [our guide to outbound data transfers from Azure](https://www.fastly.com/documentation/guides/integrations/non-fastly-services/outbound-data-transfer-from-azure) for more details. ## Using Azure Blob Storage as an origin When using Azure Blob Storage as an origin, we recommend using the [most recent version](https://learn.microsoft.com/en-us/rest/api/storageservices/versioning-for-the-azure-storage-services) of Azure storage services. Certain incompatibilities may occur if using too old a version or if the version is not specified by the request header. To enforce a version to use when not specified by the header, set the [`DefaultServiceVersion`](https://docs.microsoft.com/en-us/rest/api/storageservices/set-blob-service-properties) in your Blob storage service. Alternatively, place a VCL snippet to `vcl_miss` and `vcl_pass` to set or enforce the version. For example, if the version is `2020-06-12`, the VCL snippet would look like the following: ```vcl {{if (req.backend.is_origin) { }} {{ set bereq.http.x-ms-version = "2020-06-12"; }} } ``` Once you've configured your Azure Blob Storage stores are ready to make them available through Fastly, follow the steps below. ### Creating a new service Follow the instructions for [creating a new service](https://www.fastly.com/documentation/guides/getting-started/services/working-with-cdn-services#creating-a-new-cdn-service). You'll add specific details about your origin when you fill out the **Create a new service** fields: - In the **Name** field, enter any descriptive name for your service. - In the **Domain** field, enter the hostname you want to use as the URL (e.g., `cdn.example.com`). - In the **Address** field, enter `.blob.core.windows.net`. - In the **Transport Layer Security (TLS)** area, leave the **Enable TLS?** default set to **Yes** to secure the connection between Fastly and your origin. - In the **Transport Layer Security (TLS)** area, enter `.blob.core.windows.net` in the **Certificate hostname** field. ### Setting the default Host and correct path Once the new service is created, set the default Host to `azure` and then add your container path to the URL by following the steps below: 1. From the [**Home**](https://manage.fastly.com/home) page, select the appropriate service. You can use the search box to search by ID, name, or domain. 2. Click **Edit configuration** and then select the option to clone the active version. 3. Click **Settings**. 4. Click the **Override host** switch. ![the Add an override host header window](/img/override-host-azure-blob.png) 5. Enter the hostname of your Azure Blob Storage account. For example, `.blob.core.windows.net`. 6. Click **Save**. 7. Click **Content**. 8. Click **Create header**. 9. Fill out the **Create a header** fields as follows: - In the **Name** field, enter `Modify URL`. - From the **Type** menu, select **Request**, and from the **Action** menu, select **Set**. - In the **Destination** field, enter `url`. - In the **Source** field, enter `"/" req.url`. - From the **Ignore if set** menu, select **No**. - In the **Priority** field, enter `10`. 10. Click **Create**. 11. From the **Activate** menu, select **Activate on Production** to deploy your configuration changes. ### Testing your results By default, we create DNS mapping called **yourdomain.global.prod.fastly.net**. In the example above, it would be `cdn.example.com.global.prod.fastly.net`. Create a DNS alias for the domain name you specified (e.g., CNAME `cdn.example.com` to `global-nossl.fastly.net`). Fastly will cache any content without an explicit `Cache-Control` header for 1 hour. You can verify whether you are sending any cache headers using curl. For example: ```term nolinenums $ curl -I opscode-full-stack.blob.core.windows.net HTTP/1.1 200 OK Date: Fri, 04 May 2018 21:23:07 GMT Content-Type: application/xml Transfer-Encoding: chunked Server: Blob Service Version 1.0 Microsoft-HTTPAPI/2.0 ``` In this example, no Cache-Control headers are set so the default TTL will be applied. ## Using an Azure Blob Storage private container To use an Azure Blob Storage private container with Fastly, follow the instructions below. ### Before you begin Be sure you've already made your Azure Blob Storage containers available to Fastly by [pointing to the right container](https://www.fastly.com/documentation/guides/integrations/non-fastly-services/microsoft-azure-blob-storage#using-azure-blob-storage-as-an-origin) and setting your origin to port 443. This needs to be done before authenticating. To complete the setup, you'll also need your Azure Storage Account shared key and storage account name to construct the Azure Blob Storage Authorization header, which takes the following form: ```plain Authorization: SharedKey `Account name`:`Signature` ``` Finally, you'll also need to know your Blob Storage container name. ### Setting up Fastly to use an Azure Blob Storage private container with a Shared Key > **WARNING:** Your account's Shared Key does not have detailed access control. Anyone with access to your Shared Key can read and write to your container. Consider using a [Shared Access Signature](https://www.fastly.com/documentation/guides/integrations/non-fastly-services/microsoft-azure-blob-storage#setting-up-fastly-to-use-an-azure-blob-storage-private-container-with-a-shared-access-signature-sas) (SAS) instead. To access an Azure Blob Storage private container with Fastly using a Shared Key, first familiarize yourself with Microsoft's documentation on [authorizing with Shared Key](https://docs.microsoft.com/en-us/rest/api/storageservices/authorize-with-shared-key). Then, [create two headers](https://www.fastly.com/documentation/guides/full-site-delivery/headers/adding-or-modifying-headers-on-http-requests-and-responses): a Date header (for use with the authorization Signature) and an Authorization header. #### Create a Date header Create the Date header using the steps below. 1. Log in to the [Fastly control panel](https://manage.fastly.com). 2. From the [**Home**](https://manage.fastly.com/home) page, select the appropriate service. You can use the search box to search by ID, name, or domain. 3. Click **Edit configuration** and then select the option to clone the active version. 4. Click **Content**. 5. Click **Create header**. ![creating a date header via the header page](/img/create-new-date-header.png) 6. Fill out the **Create a header** fields as follows: - In the **Name** field, enter `Date`. - From the **Type** menu, select **Request**, and from the **Action** menu, select **Set**. - In the **Destination** field, enter `http.Date`. - In the **Source** field, enter `now`. - From the **Ignore if set** menu, select **No**. - In the **Priority** field, enter `10`. 7. Click **Create**. A new Date header appears on the Content page. You will use this later within the Signature of the Authorization header. #### Create an Authorization header Next, create the Authorization header with the specifications listed below. 1. Click **Create header** again to create another new header. ![creating an authorization header via the header page](/img/create-authorization-header-azure-blob.png) 2. Fill out the **Create a header** fields as follows: - In the **Name** field, enter `Azure Authorization`. - From the **Type** menu, select **Request**, and from the **Action** menu, select **Set**. - In the **Destination** field, enter `http.Authorization`. - From the **Ignore if set** menu, select **No**. - In the **Priority** field, enter `20`. 3. In the **Source** field, enter the header authorization information using the following format: ```plain "SharedKey :" digest.hmac_sha256_base64(digest.base64_decode(""), if(req.method == "HEAD", "GET", req.method) LF LF LF req.http.Date LF "/" req.url.path) ``` replacing `` and `` with the information you gathered before you began. For example: ```plain "SharedKey test123:" digest.hmac_sha256_base64(digest.base64_decode("UDJXUFN1NjhCZmw4OWo3MnZUK2JYWVpCN1NqbE93aFQ0d2hxdDI3"), if(req.method == "HEAD", "GET", req.method) LF LF LF req.http.Date LF "/test123" req.url.path) ``` We provide a detailed look at the [Source field parameters](https://www.fastly.com/documentation/guides/integrations/non-fastly-services/microsoft-azure-blob-storage#a-detailed-look-at-the-source-field) below. 4. Click **Create**. The new Authorization header appears on the Content page. 5. From the **Activate** menu, select **Activate on Production** to deploy your configuration changes. #### A detailed look at the Source field So what's going on in the Source field of the Authorization header? Here's the basic format: `SharedKey` It tells us the following: | Element | Description | | ---------------------- | -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | `SharedKey` | A constant placed before the storage account name. It's always SharedKey. | | `storage account name` | The name of your Azure Storage Account. We used `test123` in this example. | | `signature function` | The algorithm used to validate the key and message of the signature. We used `digest.hmac_sha256_base64(, )` in this example. | | `key` | The Azure Storage Account shared key from your Azure Storage developer's account. We used `UDJXUFN1NjhCZmw4OWo3MnZUK2JYWVpCN1NqbE93aFQ0d2hxdDI3` in this example. It must be Base64 decoded. | | `message` | The UTF-8 encoding of the StringToSign. See the table below for a break down of each portion of the message. | The message that's part of the Source field in the Authorization header takes on this basic format: `/n` It tells us the following: | Element | Description | | ----------------------- | -------------------------------------------------------------------------------------------------------------------------------------------------- | | `HTTP-verb` | The REST verb. We use `req.method` in this example. We rewrite HEAD to GET because Varnish does this internally before sending requests to origin. | | `\n` | A newline indicator constant. It's always \\n. | | `Content-MD5` | The content-md5 header value, used as a message integrity check. It's often left blank. We use `LF` (line feed) in this example. | | `Content-Type` | The content-type header value, used to specify the MIME-type. It's often left blank. We use `LF`in this example. | | `Date` | The date and time stamp. We use `req.http.Date` (which we created first as a separate header in the steps above). | | `CanonicalizedHeaders` | The x-ms headers, which customize your Azure Blob Storage implementation. It's often left blank. We use `LF` in this example. | | `CanonicalizedResource` | Your Storage Account Name. We use `"/test123"` in this example. | ### Setting up Fastly to use an Azure Blob Storage private container with a Shared Access Signature (SAS) To access an Azure Blob Storage private container with Fastly using a Service Shared Access Signature (SAS), read Microsoft's [Delegate access with a shared access signature](https://learn.microsoft.com/en-us/rest/api/storageservices/delegate-access-with-shared-access-signature) page. Then, obtain the SAS and sign the access URL. Using a Service Shared Access Signature gives you more detailed control over: - The interval during which the SAS is valid, including the start time and the expiry time. - The permissions granted by the SAS. For example, a SAS for a blob might grant read and write permissions to that blob, but not delete permissions. - An optional IP address or range of IP addresses from which Azure Storage will accept the SAS. For example, you might specify a range of IP addresses belonging to your organization. - The protocol over which Azure Storage will accept the SAS. You can use this optional parameter to restrict access to clients using HTTPS. #### Obtaining the Shared Access Signature Obtain the SAS using the steps below. 1. In the Azure portal, navigate to your storage account 2. Under settings navigate to **Shared access signature**. ![creating a shared access signature](/img/create-shared-access-signature-azure-blob.png) 3. From the **Allowed services** controls, select **Blob**. 4. From the **Allowed resource types** controls, select **Object**. 5. From the **Allowed permissions** controls, select **Read**. 6. Leave the **Start time** set to the current date and time. 7. Set the **End time** as far in the future as you are comfortable (see note below). 8. Ensure the **Allowed protocols** remain set to **HTTPS only**. 9. Click **Generate SAS and connection string**. The generated information appears. 10. Copy and save the contents of the **SAS token** field. It will look something like: ```plain ?sv=2017-11-09&ss=b&srt=o&sp=r&se=2019-10-22T15:41:23Z&st=2018-10-22T07:41:23Z&spr=https&sig=decafbaddeadbeef ``` We provide a detailed look at the [Shared Access Signature parameters](https://www.fastly.com/documentation/guides/integrations/non-fastly-services/microsoft-azure-blob-storage#a-detailed-look-at-the-shared-access-signature-parameters) below. #### Signing the URL Next, sign the access URL by creating an authorization header following the steps below. 1. Log in to the [Fastly control panel](https://manage.fastly.com). 2. From the [**Home**](https://manage.fastly.com/home) page, select the appropriate service. You can use the search box to search by ID, name, or domain. 3. Click **Edit configuration** and then select the option to clone the active version. 4. Click **Content**. 5. Click **Create header**. ![modifying the url via the header page](/img/modify-url-shared-access-signature-azure-blob.png) 6. Fill out the **Create a header** fields as follows: - In the **Name** field, enter a meaningful name such as `Set Azure private SAS Authorization URL`. - From the **Type** menu, select **Request**, and from the **Action** menu, select **Set**. - In the **Destination** field, enter `url`. - In the **Source** field, enter `req.url.path {""}` replacing `{""}` with the token you obtained from the Azure Portal. - From the **Ignore if set** menu, select **No**. - In the **Priority** field, enter `10`. 7. Click **Create**. 8. From the **Activate** menu, select **Activate on Production** to deploy your configuration changes. #### A detailed look at the Shared Access Signature parameters Microsoft's [Create a service SAS](https://docs.microsoft.com/en-us/rest/api/storageservices/create-service-sas) page provides more details on shared access signatures and how they are constructed. | Element | Description | | ------- | --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | `sv` | The `signedversion` field. This is required and should be whatever the Azure portal provided. | | `ss` | The `signedservice` field. This is required and should be `b` for "blob storage." | | `srt` | The `signedresourcetype` field. This is required and should be `o` for "object." | | `sp` | The `signedpermissions` field. This is required and should be `r` for "read only." | | `st` | The `signedstart` field. This is optional and specifies, in a UTC format compatible with ISO 8601, the time at which the shared access signature becomes valid. If omitted, the start time for this call is assumed to be the time when the storage service receives the request. | | `se` | The `signedexpiry` field. This is required and specifies, in a UTC format compatible with ISO 8601, the time at which the shared access signature becomes invalid. | | `spr` | The `signedprotocol` field. This is optional and specifies which HTTP protocol (`http` or `https`) the container should use for access. We recommend `https`. | | `sig` | The `signature` field. This is required and should be whatever the Azure portal provided. | > **WARNING:** Always keep track of the `se` expiry date. After it has passed, Fastly will not be able to access your private container. ## TCP connection settings for improved performance By default, Fastly keeps established TCP connections opened to your origin to improve performance. Azure’s default behavior, however, closes idle connections. Specifically, the Azure Load Balancer’s default behavior silently drops flows when the default idle timeout of a flow reaches four minutes. To ensure successful integration, we suggest tuning Azure in two ways: - increase the Azure Load Balancer’s [TCP idle timeout setting](https://docs.microsoft.com/en-us/azure/load-balancer/load-balancer-tcp-idle-timeout) - configure Azure to send a bidirectional [TCP Reset](https://learn.microsoft.com/en-us/azure/load-balancer/load-balancer-tcp-reset) (RST packet) on idle timeout > **NOTE:** > > This article describes how to configure an integration with a service provided by a third party. As stated in our [Terms of Service](https://www.fastly.com/terms), we do not provide direct support for non-Fastly services. > > ## Related content - [Working with hosts](https://www.fastly.com/documentation/guides/getting-started/hosts/working-with-hosts) - [Creating request headers](https://www.fastly.com/documentation/guides/full-site-delivery/headers/adding-or-modifying-headers-on-http-requests-and-responses) - [Azure Blob Storage code example](https://www.fastly.com/documentation/solutions/examples/azure-blob-storage-bucket-origin-private/)
